OUR DESIGN PROCESS
Four Agile Entry Points for You
You Have an Idea.
You Have a Concept Or Early Design.
You Have a Product That Needs Verification
Firefighting
How It Works
1
Customer Input
-
Start by listening closely
-
Define needs: frequency bands, integration, enclosure, use cases
-
Align design with business goals from day one
2
Model Build Up
Use your mechanical CAD or provide ours if in early stages •
Import and integrate into CST •
Create a unified 3D simulation model •
3
Antenna Design
-
Explore multiple antenna concepts for your product
-
Balance size, bandwidth, efficiency, and manufacturability
-
Rapidly iterate from sketches to simulation-ready designs
4
Simulation
Use simulation-first approach •
Predict antenna behavior in product environment •
Account for mechanical structures, nearby materials •
Simulate real-world factors like human body proximity •
5
Analysis
-
Benchmark results vs. performance targets
-
Evaluate performance across frequency bands
-
Assess tuning effectiveness
-
Ensure real-world robustness
6
Reporting
Get clear, actionable reports •
Include design reasoning and simulation visuals •
Tailored for internal reviews or compliance needs •
7
Delivery
-
Deliver final antenna and integration files
-
Ready for prototyping or production
-
Include radiators, grounding, and decoupling strategies
Virtual workflow graph
Data Import
• Antenna design targets
• Mechanical files
• Hardware files (data
sheet, layout, schematics)
• EMC files
• Material information
• Use cases
Virtual Proto
• Simulation model build up
• Define use cases
• Antenna design
Virtual Lab
• Running simulations
• Antenna tuning and matching optimization
Data Analysis
• Antenna parameters against design targets
• Reporting
Data Export
Antenna design mechanical files
• Radiators
• Grounding concept
• Decoupling concept
Crafting Your Ideal work package
From first sketch to final test – or anywhere in between – we help you move fast and get it right. Whether it’s antenna concepting, CST simulation, or antenna measurements, we deliver precision, speed, and results you can count on.
